SOW series single-stage double-suction split volute centrifugal pump is produced by our company based on importing the advanced technology from Germany in accordance with the market demand. By using the original and modified impeller and cutting, the pump boasts a full and wide range of spectrum and high service efficiency. The water pump can provide the working points of any flow and lift head  required by the user within the spectrum performance range. TPOW pump adopts a hydraulic model with the self-balancing axial force and radial force, which is the best both at home and abroad currently. It boasts stable performance ,high efficiency, compact structure,small vibration,strong resistance to pressure of pump body and being easy for installation and maintenance.

Sow Horizontal Split Casing Double Suction Centrifugal Water PumpMain Purpose :

  SOW series of product is widely used for water plant, irrigation ,drainage pumping station, power station, water circulation of air-conditioning, industrial water supply system, fire system and shipping industry as well as for the general purpose in the oil refining industry.

Sow Horizontal Split Casing Double Suction Centrifugal Water PumpApplication of Performance

Diameter of pump outlet:DN80-800mm
Pump flow range :Q≤11600m3/h
Pump lift head range:H≤200m
Pump working pressure:P≤2.5Mpa
Pump working temperature:T≤105ºC
Pump working voltage:U=380V,6kV,10kV
Hydraulic performance:
    It adopts the internantional advanced computer aided software and the modern design methods(namely optimum design and reliable design approach) for the hydraulic and structural design of the pump so that TPOW double-suction pump boasts efficient and noticeable resistance to cavitation. Compared with home-made like products, this series of product has a 2-4% higher efficiency and noticeably stronger cavitation resistance, which will save a lot of capital for the user .

Structural Features:
1.Compact structure ,space effective and much shorter axial dimensions.
2.Small vibration and low noise, achieved mainly by means of the follow:
A,The pump casing adopts the double-volute structure;
B,The rotor part has short axial dimensions and  a good rigidity.
C. The pump shaft adopts the imported high-precision bearing for the support.
