The CQB stainless steel magnetic force actuation pumps, is theapplication modern magnetism principle, does not have the contactindirect transmission using the permanent magnet realization one kindof chemical flow to pump, uses inside and outside magnet steel onrollers transmission, among the magnetic circuit with the isolationset the liquid seal in the isolation set, moves the seal by the staticseal generation, the thorough settlement other machineries have pumpedare unable to avoid running, braving, the drop, to leak the disease.Is suitable to the transportation virulent, is easy to volatilize, YiLou, to be flammable, explosive and the precious liquidtransportation. This pumps the structure compact, outlook artistic,volume small, noise low, movement reliable, the use service isconvenient, its technical performance achieves the overseas similarproduct the advanced level. But widely uses in domain and so onchemical, drugs manufacture, galvanization, food, petroleum,environmental protection, rare earth separation, smelting, automobilemanufacture, scientific research institution, defense industry.

 Model Significance:

CQB 40 ¨C25 ¨C 160

The CQ - magnetic force pumps
B - has flowed the part is the stainless steel
40 - imports diameters (mm)
25 - exportation diameters (mm)
160 - impellers nominal diameter (mm)
